Parameter

CONCRETE BATCHER SERIES

MAIN TECHNICAL PARAMETERS FOR CONCRETE BATCHER

Model/Item     Parameters PL800 PL1200 PL1600 PL2400 PL2400A PL2400B PL3200
Measuring hopper  volume(m³) 0.85 1.25 1.8 2.4 2.4 3×1.5 4×1.9
Storage hopper volume (m³) 2×2.2 3×3.4 3×5 3×8 3×15 3×20 4×20
Productivity (m³/h) 45 60 80 120 120 300 450
Blending accuracy ±2%
Max measuring value(kg) 1500 2000 2500 3500 3×1800 4×2200
Blending types 2 3-4 3 3 3 3-4 4

Loading height(mm)

2500 2500 3100 3500 3960 4200 4400
Belt conveyor belt speed(m/s)  1.25 1.25 1.75 1.6 1.25 1.25 1.25
Power(kw)  2.2×3 2.2×4-5 4×4 7.5 11 11 11
Total weight(kg) 2500 5280 5100 5700 8522 15000 19000
Outline dimensions(mm)
(length*width*height)
5640×1590×2671 11252×2177×3050 9042×2690×3451 9800×2748×4000 9930×3123×4300 11190×3700×6090 14820×3700×6090
