Parameter
MOBILE      CONCRETE       MIXING       PLANT      SERIES

Item/ Model       YHZS25 YHZS35 YHZS50 YHZS75
Whole machine             Theoretical productivity(m³/h) 25 35 50 75
Control mode   Computer
Weighing mode   Electrical scale
Discharging height(m)       2.8~3.8
Whole machinery capacity(kw) 50 80 100 140
Mixer       Model  of mixer   JS500 JS750 JS1000 MT1250
Mixing  power(kw) 18.5 30 18.5×2 22×2
Charging volume(L) 800 1200 1500 1750
Discharging  volume (L) 500 800 1000 1250
Diameter of macadam/pebble(mm) 40~60 40~60 40~80 40~80
Aggregate storage system Batcher scale  model PL 800 PL1200 PL1600 PL2400
Types of ingredients   2Piece 2Piece 4Piece 4Piece
Weighing range & accuracy 200~1500±2%   200~2000±2%   200~2500±2% 200~3500±2%
Powder storage system       Powder storage capacity (t)  50×1   50×1   50×1   50×2
Screw conveyor capacity(t/h)   30   35   45   55
Cement weighing range & accuracy       50~300±1%       50~450±1%       50~600±1%       100~800±1%
Water additives storage system     Water weighing range(kg)   50~150   50~200   50~350   50~450
Water weighing accuracy               ±1%
Liquid additives weighing range(kg) 5~20   5~20   5~20   5~30
Liquid additives  weighing accuracy             ±1%
